1. Rated voltage: AC90V-240V, 50/60HZ Total power: 15W
2. Signal type: DMX512 and digital signals transmitted through RS-485 interface
3. Signal input: 1 signal input, 1 direct signal output (there is electrical isolation between the signal input and the direct signal)
4. Signal output: 8 signals are distributed and output through electrical isolation. Each output has an independent MCU (microcontroller) combined with circuit processing to detect whether the "+" phase and "-" phase of the output DMX are short circuited with the signal "ground". If a short circuit occurs, corresponding alarms will be issued through the buzzer and indicator light, and the number of alarms from the buzzer can be used to determine which wire is short circuited
5. Independent power supply: The processing circuits for the input and each output signal are powered independently
6. Isolation signal prompt: indicator light indication+buzzer indication
7. MCU: There are a total of 9 MCUs with conventional DMX signal amplification functions. In addition, the software is also responsible for detecting, analyzing, and processing the status of each part of the signal
